The TP-Link TL-SG2428P JetStream 28-Port Gigabit Smart Switch delivers robust network performance and extensive connectivity with its 28 gigabit ports, including 24 Power over Ethernet (PoE+) ports. Designed for dynamic network environments, this switch supports a total PoE power budget of 250 watts, making it suitable for powering a wide range of PoE-enabled devices. The switch’s advanced features are ideal for managing high-bandwidth applications and ensuring reliable network performance in settings such as offices, retail spaces, and educational institutions.
Integrated with the Omada Software Defined Networking (SDN) platform, the TL-SG2428P allows for seamless centralized management through cloud-based and local controllers. With Zero-Touch Provisioning (ZTP), network configuration and monitoring become streamlined and efficient. This switch supports both IPv4 and IPv6, providing comprehensive network management and security features including advanced Quality of Service (QoS), robust security protocols, and intelligent monitoring.
Key Features:
-
PoE+ Capability: Equipped with 24 PoE+ ports, the TL-SG2428P supports IEEE 802.3at/af standards, allowing it to deliver up to 250 watts of total power to connected devices. This feature is ideal for powering IP cameras, wireless access points, and VoIP phones without the need for additional power supplies.
-
High-Speed Connectivity: The switch offers 24 gigabit Ethernet ports and 4 gigabit SFP slots, ensuring fast and reliable network connections. With a total switching capacity of 56 Gbps and a packet forwarding rate of 41.7 million packets per second, it efficiently handles large volumes of data traffic.
-
Omada SDN Integration: Centralized management is facilitated through Omada’s SDN platform, supporting Zero-Touch Provisioning (ZTP) and offering both cloud-based and on-premise control. This integration simplifies network setup and ongoing management.
-
Advanced Security: The TL-SG2428P incorporates multiple security features including IP-MAC-Port Binding, Access Control Lists (ACLs), and DoS protection. These measures safeguard the network from unauthorized access and potential threats.
-
Quality of Service (QoS): Optimized for voice and video applications, the switch supports L2/L3/L4 QoS and IGMP snooping to ensure high performance for multimedia applications.
-
IPv6 Support: Comprehensive IPv6 capabilities include dual stack support, MLD snooping, and IPv6 neighbor discovery, ensuring future-proof network infrastructure.
Specifications:
- Standards and Protocols: IEEE 802.3i, IEEE 802.3u, IEEE 802.3ab, IEEE802.3z, IEEE 802.3ad, IEEE 802.3x, IEEE 802.3az, IEEE 802.1d, IEEE 802.1s, IEEE 802.1w, IEEE 802.1q, IEEE 802.1p, IEEE 802.1x
- Interface: 24× 10/100/1000 Mbps RJ45 Ports (Auto Negotiation/Auto MDI/MDIX), 4× Gigabit SFP Slots
- Network Media: 10BASE-T: UTP category 3, 4, 5 cable (maximum 100m), 100BASE-TX/1000Base-T: UTP category 5, 5e or above cable (maximum 100m), 1000BASE-X: MMF, SMF
- Fan Quantity: 2
- Power Supply: 100-240V AC, 50/60Hz
- PoE Ports (RJ45): Standard: 802.3at/af compliant, PoE+ Ports: 24 Ports, PoE Power Budget: 250 W
- Dimensions (W x D x H): 17.3 × 8.7 × 1.73 in (440 × 220 × 44 mm)
- Mounting: 19" 1U rack mountable
- Max Power Consumption: 32.1 W (with no power device connected), 308.6 W (with 250W power device connected)
- Max Heat Dissipation: 109.5 BTU/h (with no PD connected), 1,052.9 BTU/h (with 250 W PD connected)
Conclusion:
The TP-Link TL-SG2428P JetStream 28-Port Gigabit Smart Switch offers extensive connectivity and management capabilities for modern network environments. Its combination of PoE+ support, high-speed ports, and integration with Omada SDN makes it a valuable asset for ensuring efficient and secure network operations. Whether used in a small office or a larger enterprise setting, this switch is designed to deliver dependable performance and advanced features.
